Please leave sufficient space (more than 50mm) around the unit for heat dissipation.ĭo not install and mount TP04 series in the following environment. DO NOT exceed this specification when tightening the screws otherwise TP04 series may be damaged. If the fixed support is not installed well, Delta will not guarantee the waterproof function. However, if a firm mounting TP04 series to the panel is needed, please use the mounting fixed support accessory which is packed together with TP04 series, then insert the fixed support in the back and tighten the screws. Please insert TP04 series to the opening hole of panel and tighten the screws. Menu, the user can use it to define functions separately when they are inį1 / F6: It is used to be constant 1 (F1) and 6 (Shift+F1) when it is in the systemį2 / F7: It is used to be constant 2 (F2) and 7 (Shift+F2) when it is in the systemį3 / F8: It is used to be constant 3 (F3) and 8 (Shift+F3) when it is in the systemį4 / F9: It is used to be constant 4 (F4) and 9 (Shift+F4) when it is in the system It is used to input a value or accept a programming command.į0 / F5: It is used to be constant 0 (F0) and 5 (Shift+F0) when it is in the system Right: This key is right direction key and it can be used to select the position of
Left: This key is left direction key and it can be used to select the position of the Pg Dn / DOWN: It is used to decrease the value or move down one page. UP / Pg Up: It is used to increase the value or move up one page. It is used to select function keys F0 ~ F9 and other keys for special function. It is used to cancel an incorrect input, or to exit a programming step. It is used to display current program status. LED will blink when communicates via RS-485 / RS-422. LED will blink when transmits program and communicates via RS-232. Status 2: When there is an abnormal situation, LED will blink quickly along with Status 1: When power is on, LED will start to blink slowly Please refer to the actual product for exact description. NOTE: The words of “MADE IN XXXXX” will be different due to the manufacturing location.
Regarding the editing software, there are various objects and images for the user’s requirements.
DELTA HMI PROGRAMMING MANUAL DOWNLOAD
The user can purchase program copy card (optional) to copy settings and programs quickly and save download time. Besides, it also supports built-in RTC, communication / alarm LED indicators.
RS-232 and RS-485 can be used simultaneously. It provides multilingual display and two built-in communication ports, one is for RS-232 / RS-422 and the other is for RS-485. TP04G-AS2 has the features of high resolution 128×64 dots and is able to display 8×4 Chinese character. DO NOT tighten the screws out of the normal torque specifications otherwise serious damage may occur. DO NOT touch any internal circuit in 1 minute after the power is switched off.ģ Make sure the groud terminal is correctly grounded in order to prevent electromagnetic interference.ģ Please use the fixed support accessory which is packed together with the product provided by Delta. Check all the wiring again before switching on the power.ģ DO NOT touch any terminal when the power is switched on. DO NOT connect input AC power supply to any of the RS-485 communication port otherwise serious damage may occur. But please prevent grease, corrosive liquids and sharp objects from contacting the TP04 series.ģ The TP04 series require 24VDC input power. 3 Please read this instruction carefully before use.ģ The display panel of TP04 series is waterproof.
